A-20 Electric Forklift – 4400 lbs Capacity, 118" Lift for Warehouse Use

A-20 Electric Forklift – 4400 lbs Capacity, 118" Lift for Warehouse Use

Regular price $14,999.00 USD
Regular price Sale price $14,999.00 USD
Limited-time Sale Sold out
Shipping calculated at checkout.
Quantity
  • Free freight shipping to 48 lower states
  • Deliver in 3-8 business days
  • 2-year manufacturer warranty

SUNMAX A-20 Electric Forklift is designed for efficient material handling in warehouses, distribution centers, and industrial environments. With a robust lifting capacity of 4,400 lbs and a maximum lift height of 118 inches, it offers exceptional performance, maneuverability, and operator comfort. Powered by an efficient AC motor system and equipped with hydraulic power steering, the A-20 is an ideal solution for mid-sized to heavy-duty indoor applications.

Key Features & Highlights

4400 lbs (2-Ton) Load Capacity – Perfect for medium-duty warehouse and industrial applications.

118 inch (9.8 ft, 3m) Max Lifting Height – Ideal for standard racking and storage needs.

Compact and Space-Saving Design -  90.5" chassis length without forks, 47“ width, and 100“ turning radius for easy navigation in tight aisles.

Efficient AC drive and lift motors – 3 kW lifting motor and 4 kW drive motor for efficient, consistent performance.

Hydraulic Power Steering – Ensures smooth, effortless maneuverability.

Long Battery Runtime – 60V/200Ah battery provides up to 4 hours of continuous operation per charge.

Applications

  • Warehousing and storage
  • Manufacturing and industrial plants
  • Logistics and distribution hubs
  • Retail stockrooms

Specifications

Performance

  • Rated Load Capacity: 4,400 lbs
  • Max Lift Height: 118 in
  • Load Center Distance: 25.98 in
  • Max Gradeability (laden): 15%
  • Max Lift Speed:
    • Unladen: 11 in/s
    • Laden: 7 in/s
  • Max Travel Speed (unladen): 9.32 mph
  • Mast Tilt Angle (Fwd/Back): 5° / 10°

Dimensions

  • Overall Length:
    • Without forks: 90.55 in
    • With forks: 138.58 in
  • Overall Width:
    • Wheel width: 47.24 in
    • Frame width: 49.21 in
  • Overall Height:
    • Mast lowered: 84.65 in
    • Overhead guard: 152.76 in
  • Adjustable Distance between Forks: 0-30.9 in
  • Wheelbase: 67.32 in
  • Front Overhang: 18.9 in
  • Front Tread: 37.8 in
  • Rear Tread: 37.8 in
  • Minimum Turning Radius: 100.39 in

Clearances

  • Ground Clearance:
    • Under mast: 4.13 in
    • Mid-chassis: 5.91 in

Power & Electrical

  • Lift Motor Power: AC 3 kW (≈ 4.02 HP)
  • Drive Motor Power: AC 4 kW (≈ 5.36 HP)
  • Battery Capacity: 200 Ah
  • Rated Voltage: 60 V
  • Charger Input Voltage: 110 V
  • Operating Time per Charge: ~5 h

Steering & Weight

  • Steering Type: Hydraulic Power Steering
  • Vehicle Weight: 7,054.78 lbs

Shipping Policy

Once the order is placed, you will receive the machine in 2-8 business days.

RETURN & REFUND POLICY

2 years Warranty (Sunmax will ship the non-wearable parts to clients in two years) 30 days free return.

Warranty: 2 years parts

2 years Warranty (Sunmax will ship the non-wearable parts to clients in two years)
